Technical data:

1.Supply voltage: (9～32)VDC

2.Output signal: 4-20mA,2-wire

3.Max.load: ≧4.7k0hm

4.Current consumption: ﹤4mA

5.Pressure range :0-25 bar

6.Over pressure safety: 40 bar

7.Burst pressure:50 bar

8.Life expectancy:5.000.000 (operations)

9.Accuracy: ±0.5 % FS (at room temperature)

10.Long term stability: ± 0.25%FS p.a.

11.Repeatability: ± 0.1% FS(at room temperature)

12.Temperature failure: ± 0.03% FS/℃

13.Temperature compensation: 0℃...+70 ℃ max. ﹤2%

14.Temperature ambient: -40℃....+100 ℃

15.Temp.-range media:-40℃...+120 ℃

16.Housing: stainless steel  (AISI 304)

17.Material in contact with the  medium:stainless steel  (AISI 316)

18.Measurement cell:diffused silicon

19.Sealing material: All welded process, no rubber material

20.Torque safety: 40N.m

21.Insulation resistance: ﹥ 100 Mohm (35VDC)

22.Resistance against vibrations: 20g/4-2000 Hz Sine DINEN 60068-2-6

23.Resistance against shock: 500m/S²; 11ms semi-sine DIN EN 60068-2-27

24.Degree of protection:IP65

25.EMC: EMV 2014/30/EU, EN61000-6-2:2005, EN61000-6-3:2007
